Examples of Circuit Board Design and Completed Enclosed Products

Flex Circuit Design for high speed digital micro display drives and low noise analog with IR light source detection

High power motor pump drive board (over 500 watts)

High wattage powering

Line scan camera, CCD camera and a photo diode amplifier

Low power RF inductive charging circuits

High power over 10 Watts RF inductive charging circuit boards

Mixed signal circuit interface board with thermistors, fluid and air pressure sensors combined with an IR sensor masking as a thermocouple

Close up view of forward-looking IR sensor

Novel shaped low mixed signal and power drive designs

PID controller for thermoelectric cells

USB over fiber (for electrically isolated serial communications for a medical device)

Wire (RF) controller and Wi-Fi cellular security camera

Full bridge high power high voltage multiplier

Full bridge and Walton Cockroft high voltage multipliers

Marx high voltage multipliers

Plastic optics

Plastic optics mounted on electro-optical hardware

Examples of high speed USB on rigid flex

Electro-optical hardware for flouresence with RFID reader antenna

Battery-powered portable electro-optical hardware with RFID reader antenna

Camera board for fingerprint ID

Plastic optics for fingerprint capture (wave guiding and frustrated internal reflection)

Broadband high speed low noise amplifier used for fast PMT pulse detection
